EasyDRAIN Compact Slim Pit is used as an accessory component with the EasyDRAIN Compact Range. The slim pit is the collection point for debris that has entered the drainage system.

83540G

265 W x 138 W x 255mm H

EasyDRAIN Compact Slim Pit is used as an accessory component with the EasyDRAIN Compact Range. The slim pit is the collection point for debris that has entered the drainage system.

Made in Australia, from 100% recycled polymer, EasyDRAIN Compact channel is a sustainable and eco-friendly drainage choice for homeowners and installers.  With a shallow, yet functional internal channel depth of 80mm and components to suit various configurations, EasyDRAIN Compact can effectively hold and distribute surface water efficiently.



Features:

  • 265 L x 138 W x 80mm H, 80mm internal channel depth
  • Polymer is UV stabilised to increase product life and durability
  • 1.5-tonne wheel loading
  • 230L/min/ metre flow rate
  • System components available include: tee piece, corner piece, end cap, converter, slim pit
  • Suitable for: outdoor areas, low rainfall and water flow areas, gardens and walkways
  • Not suitable for:  salt and chemical affected areas (pools, coastal areas)
  • 5-year warranty on polymer products



Installation Information:

  • Converters are used to make any connection either male or female depending on what two pieces are being connected
  • Connection to stormwater pipes can be made by using the 90mm moulded bottom outlets
  • View the installation video here



Sustainability features:

  • Drainage comes with minimal packaging
  • Manufactured from 100% recycled polymer
  • Polymer made in Australia



If you are looking for Revit files – contact us at [email protected]

*Note: Pressed Galvanised Steel Grate is not suitable for driveways, around swimming pools or areas subject to salt water environments such as coastal areas.

Product variation

Code Product Name Product Specifications RRP($)
83540 EasyDRAIN Compact Slim Pit with Polymer Grate 265 L x 138 W x 255mm H
83800 EasyDRAIN Standard Slim Pit with Polymer Grate 265 L x 138 W x 255mm H
83802 EasyDRAIN Standard Slim Pit with Galvanised Steel Grate 265 L x 138 W x 255mm H
83801 EasyDRAIN Standard Slim Pit with Stainless Steel Grate 265 L x 138 W x 255mm H

*All prices are recommended retail inclusive of GST in AUD. To be used as a guide only, prices may vary between model variations, and are subject to change without notice. A number of brands and products on this website are the subject of registered trade marks, register designs and/or registered patents.
